Download notebook · View source · Open in Colab

Work with Images

An Image stores image data together with metadata properties. ApertureDB can filter images by those properties and return their bytes. This example adds a food photograph, retrieves and updates its metadata, and deletes it.

The examples require Python 3.10 or later, an ApertureDB connection profile or environment credentials, and permission to create, read, update, and delete objects. A unique documentation_run property separates the example data from other records. Cleanup uses that value, so keep the setup variables available until cleanup completes.

Connect to ApertureDB

ApertureDB Cloud The SDK connects with an API key from your Cloud instance. Obtain the key from Connect > Generate API Key and add it to a .env file in this directory:

APERTUREDB_KEY=your_key_here

Local evaluation: follow the deployment guide, then configure your connection profile.

%pip install --quiet "aperturedb==0.5.1" "python-dotenv==1.1.1"

Note: you may need to restart the kernel to use updated packages.

# Option A: ApertureDB Cloud
from dotenv import load_dotenv
load_dotenv()  # loads APERTUREDB_KEY from .env into the environment

False

# For local evaluation, configure the profile from your versioned deployment package.
# https://docs.aperturedata.io/administration/deployment/DockerCompose

from aperturedb.CommonLibrary import create_connector

client = create_connector()

import uuid

documentation_run = uuid.uuid4().hex
ingredient_class = "CookbookIngredient_" + documentation_run
connection_class = "CookbookIngredientLink_" + documentation_run

def checked_query(query, input_blobs=None):
    response, output_blobs = client.query(query, input_blobs or [])
    assert isinstance(response, list) and len(response) == len(query), response
    for command in response:
        result = next(iter(command.values()))
        assert result.get("status") == 0, response
    return response, output_blobs

response, _ = checked_query([{"GetStatus": {}}])
client.print_last_response()

[
    {
        "GetStatus": {
            "info": "OK",
            "status": 0,
            "system": "ApertureDB",
            "version": "0.19.15"
        }
    }
]

Create or Add an Image of a Dish to ApertureDB

AddImage stores the supplied photograph with properties describing the dish. The image bytes accompany the JSON command as an input blob.

The Python SDK loaders handle bulk ingestion.

# Download the sample file needed in this example
from pathlib import Path
from urllib.request import urlopen
import hashlib

fixture_path = Path("data/focaccia_brittany.jpg")
fixture_path.parent.mkdir(exist_ok=True)
fixture_url = "https://raw.githubusercontent.com/aperture-data/Cookbook/e333f6c59070b9165033d9ddd5af852a6b9624ba/notebooks/simple/data/focaccia_brittany.jpg"
fixture_sha256 = "4b104ba601ab3bf1126579e9dc795842551fc25be9ab2640795da2fb461f7061"
if not fixture_path.exists() or hashlib.sha256(fixture_path.read_bytes()).hexdigest() != fixture_sha256:
    with urlopen(fixture_url, timeout=60) as response:
        fixture_path.write_bytes(response.read())
assert hashlib.sha256(fixture_path.read_bytes()).hexdigest() == fixture_sha256
print("Verified fixture:", fixture_path.name)

Verified fixture: focaccia_brittany.jpg

query = [{
    "AddImage": {
        # Notice the missing "class" property since we already know its an Image (represented as _Image in ApertureDB)
        "properties": {
            'documentation_run': documentation_run,
            "name": "Focaccia",
            "id": 35,
            "contributor": "Vishakha",
            "category": "starter",
            "cuisine": "Italian",
            "location": "Brittany",
            "caption": "fresh made focaccia with herbs from the garden"
        },
        "if_not_found": ['all', ['$id', '==', 35], ['$documentation_run', '==', documentation_run]]
    }
}]

# Read the image data as a binary blob
fd = open("data/focaccia_brittany.jpg", 'rb')
image_arr = [ fd.read() ]
fd.close()

response, blobs = checked_query(query, image_arr)

client.print_last_response()

[
    {
        "AddImage": {
            "status": 0
        }
    }
]

Query image by its metadata attributes

FindImage selects the photograph by its metadata and returns its property values.

from IPython.display import Image, display

query = [{
    "FindImage": {
        "constraints": ['all', ['all', ['$name', '==', 'Focaccia'], ['$location', '>', 'A']], ['$documentation_run', '==', documentation_run]],
        "blobs": True,                          # This is set to False by default
        "results": {
            "all_properties": True
        }
    }
}]

response, blobs = checked_query(query)

client.print_last_response()
for image_blob in blobs:
    display(Image(data=image_blob))

assert response[0]["FindImage"]["returned"] == 1
assert response[0]["FindImage"]["entities"][0]["name"] == "Focaccia"
assert len(blobs) == 1 and blobs[0]

[
    {
        "FindImage": {
            "blobs_start": 0,
            "entities": [
                {
                    "_blob_index": 0,
                    "_uniqueid": "10.2.1160",
                    "caption": "fresh made focaccia with herbs from the garden",
                    "category": "starter",
                    "contributor": "Vishakha",
                    "cuisine": "Italian",
                    "documentation_run": "52f2248299804531b551f6658fa4b3c3",
                    "id": 35,
                    "location": "Brittany",
                    "name": "Focaccia"
                }
            ],
            "returned": 1,
            "status": 0
        }
    }
]

jpeg

Update properties of the image already in ApertureDB

UpdateImage changes existing metadata values or adds properties to matching images.

query = [{
    "UpdateImage": {
        "properties": {
            "recipe_url": "https://www.allrecipes.com/recipe/23451/fantastic-focaccia-bread/"     # property will get added if missing or the value will be updated
        },
        "constraints": ['all', ['$name', '==', 'Focaccia'], ['$documentation_run', '==', documentation_run]],
    }
}]

response, blobs = checked_query(query)

client.print_last_response()

[
    {
        "UpdateImage": {
            "count": 1,
            "status": 0
        }
    }
]

query = [{
    "FindImage": {
        "constraints": ['all', ['$name', '==', 'Focaccia'], ['$documentation_run', '==', documentation_run]],
        "results": {
            "all_properties": True
        }
    }
}]

response, blobs = checked_query(query)

client.print_last_response()

assert response[0]["FindImage"]["entities"][0]["recipe_url"].startswith("https://")

[
    {
        "FindImage": {
            "entities": [
                {
                    "_uniqueid": "10.2.1160",
                    "caption": "fresh made focaccia with herbs from the garden",
                    "category": "starter",
                    "contributor": "Vishakha",
                    "cuisine": "Italian",
                    "documentation_run": "52f2248299804531b551f6658fa4b3c3",
                    "id": 35,
                    "location": "Brittany",
                    "name": "Focaccia",
                    "recipe_url": "https://www.allrecipes.com/recipe/23451/fantastic-focaccia-bread/"
                }
            ],
            "returned": 1,
            "status": 0
        }
    }
]

Delete the image

DeleteImage removes the image selected by its metadata and this run's identifier.

query = [{
    "DeleteImage": {
        "constraints": ['all', ['$name', '==', 'Focaccia'], ['$documentation_run', '==', documentation_run]]
    }
}]

response, blobs = checked_query(query)

client.print_last_response()

[
    {
        "DeleteImage": {
            "count": 1,
            "status": 0
        }
    }
]

Verify deletion

After deletion, the same image query returns no matches.

query = [{
    "FindImage": {
        "constraints": ['all', ['$name', '==', 'Focaccia'], ['$documentation_run', '==', documentation_run]],
        "results": {
            "all_properties": True
        }
    }
}]

response, blobs = checked_query(query)

client.print_last_response()

assert response[0]["FindImage"]["returned"] == 0

[
    {
        "FindImage": {
            "returned": 0,
            "status": 0
        }
    }
]
